Especificações técnicas do CLW E 13CBM LIGCOR COMPACTOR TROURCO ：
| Main Technology Parameter | |
| Model Name | CLW Brand E 13cbm garbage compactor Truck |
| Driving Type | 4x2 |
| Color | white and blue or based on client’s request. |
| Number of Cabs | 3 |
| Weights | |
| GVW(kg) | 18000 |
| Rated Payload Weight(kg) | 11500 |
| Curb Weight(kg) | 6370 |
| Dimensions | |
| Wheelbase(mm) | 4500 |
| Front/Rear Overhang(mm) | 1490/2795 |
| Approach/Departure Angle | 16/13 |
| Overall Dimension(mm) | 9045x2550x3200 |
| Max Speed(km/h) | 90 |
| Engine | |
| Engine Model | TZ366XS50E |
| Emission Standard | / |
| Engine Type | Permanent magnet synchronous motor |
| Max.Output(kw) | 120/200(272hp) |
| Drive Line | |
| Transmission | 4 forwards,1 reverse gear,AMT |
| Steering | Power steering |
| Brake | Air brake system(front and rear drum brakes) |
| Axle | |
| Front Axle | Dena 6.5 tons |
| Rear Axle | Dena 11.5tons |
| Tire Specification | |
| Tire Specification | 295/80R22.5 18PR |
| Front Wheel Track(mm) | 2016 |
| Rear Wheel Track(mm) | 1868 |
| Number of Leaf Springs | 8/10+7,3/4+3 |
| Garbage Compactor Box | |
| Volume | 13m³ |
| Raw Material | Qste420tm(side 5mm, and bottom 5mm) |
| Power Take-off Method | Electric power take-off |
| Rated power of the mounted motor | 30/45kw |
| Sewage Tank | The filler:500L |
| side-mounted auxiliary sewage tank:450L | |
| Volume of the Filler | 1.8cbm |
| Abti-corrosion for Upper Body | All structural components are powder-coating in standard Glacier White. Powder coating in other colors requires customization |
| Loading Capacity | 9000kg |
| Number of Garbage Bins Loaded(bins) | Around 270 full 240L bins |
| Applicable Standard Garbage Bin Types | 120L,120L double,240L,240L double,660L |
| Operation | Central control screen(in the cab)+ operation panel |
Descrição do produto:
Configurações funcionais: skate, raspador, mecanismo de levantamento de balde, braço de 660L, placa de pressão, placa de tampa da porta de enchimento pneumática, tanque de esgoto auxiliar montado lateral. Proteção lateral: tampa da bateria da placa de alumínio padronizada + proteção lateral da liga de alumínio. Operação a bordo: tela de controle central no painel de operação CAB +.
Other configurations: Airbag seat for the driver, four-way adjustable genuine leather seat, remote control central lock, electric window lift, multifunctional steering wheel with cruise control, 12.3-inch liquid crystal central control screen, 360-degree surround view function, integrated electric rearview mirror with heating function, single-cooling air conditioner + PTC (Positive Temperature Coefficient), rotary gear shift, EPB (Electronic Parking Brake) electronic parking brake, Painel de instrumentos digitais de cristal líquido completo de 12,3 polegadas, gravador de acionamento, retenção automática, monitoramento de pressão dos pneus, ABS (sistema de freios antibloqueio), Assistência de energia eletro-hidráulica, sistema de freio de ar (freios a tambors dianteiro e traseiro).
