Especificações técnicas do caminhão compactador de lixo de 10cbm:
| Main Technology Parameter | |
| Model Name | brand 16cbm garbage compactor truck |
| Driving Type | 4×2, |
| Color | White color or based on client's request. |
| Weights | |
| Rated payload weight(kg) | 8280 |
| Curb weight(kg) | 5950 |
| Dimensions | |
| Wheelbase(mm) | 3815 |
| Overall Dimension(mm) | 7355*2320*2750 |
| Max speed(km/h) | 105 |
| Engine | |
| Engine model | 4KH1CN6LB or 4KH1CN6HB |
| Emission standard | Euro 6 |
| Engine type | Vertical/in-line/water-cooling/ four-stroke/ supercharged inter cooler |
| No. of cylinders | straight-6 cylinders, diesel |
| Displacement(L) | 2.999L |
| Max. output (kw) | 88/97 (120HP) |
| Drive Line | |
| Transmission | 5 forwards,1 reverse gear, manual operation |
| Steering | Power steering |
| Brake | Oil brake with vacuum pump |
| Axle | |
| Front axle | Dena 3 tons |
| Rear axle | Dena 5.28 tons |
| Tire specification | |
| Tire specification | 7.50R16LT 14PR |
| Garbage compactor box | |
| Volume | 10 cbm |
| Raw material | Q345 carbon steel, side is 4mm, and bottom is 5mm. |
| Loading Method | Rear loader, waste bins flipover mechanism, can match 2 units 120 L, or 1 unit 240L and 1 unit 660L waste bins |
| Unloading Method | The back garbage filler unit is lifting up first, then garbage is pushed out by pushing plate |
| Compacted Ratio | 01:00.8 |
| Crushing Force | 13 tons |
| Control Method | Double side control box + manual levers |
| PLC; one-key cycling + half-auto control | |
| Sewage Tank | One unit |
| Others | The bottom box and filler unit are made of thick steel plate. The back filler unit lifting cylinder is equipped with a locking device. The upper part is equipped with a function of repeated compression and bidirectional peristaltic compression, an integrated flashlight operation mode, and a double-sided control box. |
| Camera | 2 units; one is for reverse image, and one is for checking the working condition. |
